P35i Fireplace Insert
Pellets or Corn/Pellet Mixture Only
Save These Instructions
3-90-775R15_04/13
D. Before Your First Fire
• Be sure the appliance is installed properly and
that all safety requirements have been met.
Pay particular attention to the clearances to
combustibles, oor protection and the venting
instructions.
• Testyoursmokedetector(s)andCOdetector(s)to
thespecicationsofthemanufacturer.
• Doublecheckthattheashpanandinternalrebox
areempty.
• Besuretoreadthisentiremanual.
E. Draft Test Procedure
• Usinga 9/16"wrench, removethedrafttestport
plugbolt,locatedtotheleftinsidetherebox.This
boltthreadsdownwardthroughtheoutsideofthe
body.Externally,theopenedholeislocatedabove
theashpanspringlatchontheleft.
• Insert
thedraft
meter
hoseinto
thetest
port.
• Besure
themeter
iscapable
ofascale
between0
and1inch
Water
Column.
Zerothemeterifnecessary,andbesureitisset
uptoreadinnegativepressure.
• Besuretheashpan,door,andhopperlidareall
closedandlatched.
• Turnthefeedadjusterto"Test"mode.
• During the rst minute of test, the combustion
blower will be on high. Record the high draft
reading here____________-W.C.The high draft
shouldbeabove-0.5"W.C.butnohigherthan-1"
W.C.
• After a minute, the combustion blower will go
to low speed. Here you want to see a reading
between-0.30"and-0.35".Ifnecessary,adjustthe
draftvoltageusingthelowdraftadjustmentscrew
on the circuit board (See Page 24). Clockwise
will increase the draft and counter-clockwise will
decreaseit.
• Once set, record the low draft reading
here:___________-W.C.
• Be sure and turn offof "Test" mode. Disconnect
themeterandreturntheplugbolttothetestport.
F. Starting a Fire - "MANUAL"
1. Withthemodeselectorinthe"OFF"position,and
theFeedAdjusterNOTon"Test",plugthepower
cordintoaproperlygroundedreceptacle.
2. FillthehopperwithDRYfuel.
3. TurntheFEEDADJUSTERdialto"Test".Thiswill
runthefeedmotorforoneminute.Ifyoubeginto
see fuel entering the burn pot, you can stop the
testcycle.Returnto#4or#5tostartout.
4. Turnthemodeselectordialtothedesiredmode.
This will start the combustion blower operating.
If Room Temp is selected, be sure to turn
the temperature dial above the current room
temperature.
5. Filltheburnpotwithamixtureofwoodpelletsand
startinggel.
6. Lightthestartinggelwithamatch,andclosethe
door.
7. OnlyaftertheESPtemperatureincreases,willthe
feederstartoperatingtoincreasetheresize.
NEVER APPLY STARTING GEL TO THE FUEL IN
THE BURN POT WITHOUT THE COMBUSTION
BLOWER OPERATING.
WARNING
TESTED AND APPROVED FOR USE WITH WOOD
PELLETS OR A MIXTURE OF SHELLED CORN AND
PELLETS ONLY. USE OF ANY OTHER TYPE OF FUEL
WILL VOID THE APPLIANCE WARRANTY.
The optimal method of operation is in Room Temp
mode, with the Ignition switch set to Automatic.
"NEVER USE GASOLINE, GASOLINE-TYPE
LANTERN FUEL, KEROSENE, CHARCOAL
LIGHTER FLUID, OR SIMILAR LIQUIDS TO
START OR "FRESHEN UP " A FIRE IN THIS
HEATER. KEEP ALL SUCH LIQUIDS WELL
AWAY FROM THE HEATER WHILE IN USE".
WARNING
