Harman PC45 User Manual

21 pC 45 Corn/pellet Stove
3-90-02686R29_05/14
ESP
Fig. 37
Be careful not to damage
ESP when cleaning with
brush.
Maintenance
8. Useabrushtocleantheue,beingcarefulnottodamage
theESP.Theuegoesstraightthroughintotheventpipe
therefore, the vent pipe can also be cleaned to some
extentthroughtheueoutlet.
9. Reinstalltheblowercoverandrelatch.
10. Slidetheashpanintothestoveandcloseandlatchthe
door.
NOTE:ASHES MAY BE FINER THAN YOUR VACUUM
FILTER.USECAUTIONWHENVACUUMINGANDKEEP
FILTERCLEAN.
Cleaning of Feeder Fines Area (Fig. 36)
1. Removetherearshieldstoaccessthefeedercover.
2. Removethewingnutonthefeedercoverandslidethe
coveroffthethreadedrod.
3. Removeallneswithavacuum.
4. Replacethefeedercoverandrearshields.
Fuel Fines may build
up in this area
(Cleaningcontinued)
5. Removetheashpan.
6. Remove the combustion blower cover by turning the
blower cover latch vertical as shown in Fig. 32. Slide
thecoveroutoftheslotontheleft.Thiswillexposethe
combustionblowerwheelandueoutlet.Fig.33.
7. Clean the blower wheel with a brush and a vacuum
cleaner.
Soot and Fly Ash
Formation and Need For Removal- The products of
combustion will contain small particles of y ash. The y
ashwillcollect in the exhaust venting system and restrict
theowoftheuegases.Incompletecombustion,suchas
occursduring startup, shutdown, or incorrect operation of
theroomheater,willleadtosomesootformationwhichwill
collectintheexhaustventingsystem.Theexhaustventing
systemshouldbeinspectedaftertherstmonthofburning
todeterminethefrequencyofcleaningthatwillberequired,
andatleastyearlythereafter.NOTE:Thefrequencycould
varyfromonceamonthtoonceaseasondependingonthe
qualityofthefuelbeingused.
IfYouExperienceAChimneyFire;DoNOTdisconnectpower
totheappliance.DoNOTputwateronthere.
TurntheselectordialtotheOFFpositionandallowtheunit
toshutdownonits'own.Havetheapplianceandventing
systemprofessionallyinspectedandcleanedpriortousing.
Latch "closed "with blower
cover in place.
Fig. 32
Fig. 31
ESP
Exposed blower wheel and ue
opening, NOTE: ESP is visible.
Blower cover removed.
Fig. 33 Fig. 34
Fig. 36
