Installation
Installing
Placethestoveonanoncombustibleoororoorprotectorthatextendsa
minimumof6"(152mm)tothefrontoftheloaddooropening,6"(152mm)
tothesidesofthedooropening,and6"totherear.Floorprotectionmust
alsoextend2"(51mm)beyondeachsideofanyhorizontaluepipe.The
minimumoorprotectormaterialis20gaugesheetmetal.Otheroor
protectormaterialsareceramictile,stone,brick,etc.
NOTE for Canadian installation only:PerULC-S627-00,Ifinstalled
on a combustible oor, the need to provide a noncombustible oor
protector coveringtheareabeneaththespace heater andextending
atleast17.72"(450mm)ontheringsideandatleast7.87"(200mm)
ontheothersides.
In Canada, you may follow smaller U.S. oor protection
requirements ONLY if the user agrees to completely shut-down
the appliance, and allow it to cool to where all re is extinguished
and the combustion blower and its indicator light shuts off, prior
to opening the rebox door or ash door.
Placethestoveawayfromcombustiblewallsatleastasfarasshownin
Figures3and4.Pleasenotethedifferenceinsidewallclearancewith
andwithoutsideshields.
Notethattheclearancesshownareminimumforsafetybutdonotleave
muchroomforaccesswhencleaningorservicing.Pleasetakethisinto
accountwhenplacingthestove.
Connectthepowercordtoa120VAC,60Hzgroundedreceptacle.(A
surgeprotectorisrecommendedtoprotectthecircuitboard.)Alsobe
surethatthepolarityoftheoutletthatthestoveispluggedintoiscorrect.
Priortoinstallingtheuepipe,connectadraftmeter.(Thedraftmeter
musthaveaminimumrangeof0-.5")Recordtherstreading.Connect
uepipetostoveandbesurealldoorsandwindowsinthehomeare
closed.Recordtheseconddraftreading_______.Ifthesecondreadingis
morethan.05"lowerthantherstreading,checkforpossiblerestrictions
or the need for outside air. For more information on the draft test
procedure,refertothedraftadjustmentprocedurelocatedinthismanual.
Mobile Home Installation
Wheninstallingthisunitinamobilehome,severalrequirementsmust
befollowed:
1. Theunitmustbeboltedtotheoor.Thiscanbedonewith1/4"lag
screwsthroughthe2holeslocatedinthebaseplate.
2. Theunitmustalsobeconnectedtooutsideair.
3. Floorprotectionandclearancesmustbefollowedasshown.
4. Unitmustbegroundedtothemetalframeofthemobilehome.
CAUTION: This appliance must be vented to the outside.
Duetohightemperatures,thestoveshouldawayfromtrafc,furniture
anddraperies.
Childrenandadultsshouldbealertedtothehazardsofhighsurface
temperaturesandshouldstayawaytoavoidburnstoskinand/orclothing.
Young children should be carefully supervised when they are in the
sameroomasthestove.
Clothing and other ammable materials should not be placed on or
nearthisunit.
Minimum size rectangular oor protection (USA) is
28
5/16
"DeepBy24
3/4
"Wide.
*Floor protection dimensions for the front and sides are
measured from the appliance door opening in The United
States.InCanada,thesidedimensionismeasuredfromthe
widestpartoftheappliance.
L
J
Floor Protection
Requirements
US
Canada
Sides
Rear
6" 200mm
6" 200mm
K
Front
6" 450mm
Fig. 3
9"(228mm)With Side Shields
13"(330mm) Without Side Shields
Fig. 4
2"(51mm)
36"(914mm)
14" (355mm) with
side shields
18" (457mm)
without side shields
14" (355mm)
18" (457mm)
9"(228mm)-
13"(330mm)
9"(228mm)- 13"(330mm)
Alternate floor protector
dimension may be used
as long as they satisfy the
measurement requirements
shown below.
Minimum size oor protection
for a corner installation 3
pad is 36" x 36". Clearance
shown as 9" with optional side
shields installed.
J
USA
K
L
J
CANADA
NOTE:
Measurement"L"is
measuredfromthe
pedestalbasein
theUSONLY
NOTE:
Measurement"K"
ismeasuredfrom
theglassintheUS
ONLY
Floor protector
THE STRUCTURAL INTEGRITY OF THE
MANUFACTURED HOME FLOOR, WALL, AND CEILING/
ROOF MUST BE MAINTAINED.
DO NOT INSTALL IN SLEEPING ROOM.
WARNING
!
