3 pC 45 Corn/pellet Stove

3-90-02686R29_05/14

Assembly and Installation

Fig. 1

Unpacking

ThePC45isboltedtotheskidtopreventmovementduring

shipping.

Tofreethestovefromtheskidyoumustremovethehold-

downboltsintherearofthepedestalbase.

Removing or Installing rear panels

Toremovetherearcoverpanels,loosenthescrewsslightly

andslidethecoversoutwardasshowninFig1.Toreinstall,

simplyslidebackintoplaceandretightenthescrews.

Ifneeded,installthe(2)5/16-18X3/4”levelingboltslocated

inthehardwarekit.Fig1.

Firebrick

Installthethree (3) rebrick vertically on the angle above

theburnpot.Fig.2

Followtheseinstructionsalongwithalllocalcodesregarding

installationofthisappliance.

Do NOT use makeshift compromises when installing this

appliance,seriousconsequencesmayresult.

Withanyhearthappliance,installationofsmokedetectors

isrecommendedoneverylevelofthehome.

Possible causes of smoke detector activation:

Paintcuringprocess-Openawindowneartheappliance

fortherstfewhoursofburning.

Exhaustbeingdrawnbackinsidethedwelling-Outsideair

connectiontotheapplianceisnecessary.

Ventleakage-Allinteriorseamsandjointsshouldbesealed

withsiliconewhereapplicable. Follow vent manufacturers

instructionsforpropersealing.

Fig. 2

RearCover

Panel

Shipping Bolts

Note:Thesesameholesareusedfor

securing the stove inmobile home

installation.

RearCover

Panel
