Harman PF-120 User Manual

Harman® • PF-120 Owner’s Manual_R3 • 2014 -___ • 10/1434
3-90-08120c
F. Quick Reference Guide Quick Reference Guide ( Auto-Light ) 1. TurnModeSelectortoOFF. 2. Useshakerhandletocleantheheatexchangertubes.** 3. Scrapetheairholesintheburnpot.** 4. Fillthehopperwithpellets. 5. TurnFeedAdjusterto“Test”.* 6. ChecktheCombustionBlowerandFeederMotorforoperation.* 7. TurnFeedAdjusterbacktothe#4setting. 8. TurntheTempDialtothedesiredtemperature. 9. TurnallotherFurnaceControlknobstothesettingsshown.* 10. FliptheAuto-Lightswitchup.* Thefurnacewilligniteifthetemperatureintheroomislessthanthetemperature setontheWallControl.
* See the section on Operation for information about Manual Lighting.
** See the section on Maintenance for more details about cleaning.
Temp Dial Mode Selector
“Test”

Harman PF-120 Specifications

General

Brand	Harman
Model	PF-120
Category	Furnace
Language	English
