22
Dry Seasoned Wood Only!
TL2.6 Woodburning Stove
Save These Instructions3-90-08570
A. Outside Air Attachment
Parts and Supplies Needed: Kit #1-10-856082, 1 piece of
metal exible pipe, 4" X needed length. 1 Rodent Screen,
and aluminum tape. Plus, a trim ring for nishing around the
pipe on the inside wall.
1. Determine an appropriate hole location, through the
wall. Be sure there are no studs or other supporting
members. Also ensure there are no electrical wires or
plumbing contained within the wall.
2. Make the hole through the exterior wall using a hole
saw or reciprocating saw. You'll want the hole to be just
slightly larger than the metal ex pipe.
3. Attach the rodent screen to one end of the ex pipe,
and insert it through the wall until the back of the screen
cover is against the outside surface.
4. Hold the ex pipe in place to make an accurate
determination of the length needed. Cut the ex pipe
to length.
5. Slide the trim ring onto the ex for the inside wall portion.
6. Slide the other end of the metal intake ex pipe into
the stub on the rear of the stove and secure it with
aluminum tape. This air intake will supply outside air for
the secondary combustion.
7. Secure the trim ring in place for nishing the inside wall
area.
8. Seal around the rodent screen on the exterior wall,
using silicone caulking.
B. Leveling the Appliance
Use metal shims for leveling with the pedestal base. When
the leg option is chosen, each leg has a leveling adjuster.
C. Optional Cooking Grill
The optional cooking grill #1-00-08121 installs easily in the
top load opening of the TL2.6.
The grill handle (B) ts in the slots (C) on each side. To
remove the handle, lower and turn.
When installed, the grill hangs in the opening by the hooks
(A).
When grilling, you'll want to keep the re size small and
the bypass damper in the open position. Depending on the
grilling being done, you may get grease splashing onto the
glass causing it to become dirty and obstructed. When you
burn your next hot re, the glass will likely clean itself.
Section 7 - Appliance Set-Up
NEVER DRAW OUTSIDE COMBUSTION AIR FROM:
WALL, FLOOR OR CEILING CAVITY.
ENCLOSED SPACE SUCH AS AN ATTIC OR
GARAGE
CAUTION
Outside Air
Attachment
A
A
A
B
C
C
