23
Save These Instructions
TL2.6 Woodburning Stove
Dry Seasoned Wood Only!3-90-08570
Plug the blower into a properly grounded electrical outlet.
Keep the blower on low speed or off during low res. As
you get out of the low burn range, the speed can be set
wherever desired, or kept off.
D. Optional Blower Installation
Use ONLY Blower Part #1-00-856002 With This
Appliance.
The optional blower kit installs easily to the rear of the TL2.6.
First, remove the air jacket shield from the rear of the stove.
Use the same four bolts to attach the blower as shown.
E. Brushed Stainless Trim Kit Option
The trim kit consists of three pieces; Load door trim, Ash lip
trim, and the Ash door frame. To install the load door trim, it
is best to remove the door by lifting from the hinges. lay the
door down at on it's face. Drill the dimpled holes in each
corner of the door and re-install the door onto the stove.
From the outside, install the frame with the studs going
through the newly drilled holes and install the nuts on the
inside. To install the ash lip trim, just slide it onto the ash lip.
You may attach with silicone if desired. The ash door frame
can only be used with the pedestal option. It uses a spring
clip on one end to hold it into the recessed area of the ash
door. Install the clip in the frame channel and push that end
into the door opening until the other end of the frame ts.
ROUTE POWER CORD AWAY FROM THE APPLIANCE.
DO NOT RUN THE CORD UNDER OR IN FRONT OF
THE APPLIANCE.
WARNING
