Harman TL 2.6 User Manual

Service Parts
TL2.6 W/Pedestal
Beginning Manufacturing Date: Sept 2011
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Hardware Packages
#10-24 x 1/4” Alloy Steel Black Oxide Cup Point SSS Pkg of 100 3-30-2006-100
Y
Acorn Nut, 10-24 Nickel Plated Pkg of 50 3-30-8014-50
Y
Ball Plunger, 5/16 x 1/2 Pkg of 3 3-31-5500-3
Y
Bolt, Case Hardened Zinc Flange, 1/4-20 x 3/8 Pkg of 50 3-30-2000-50
Y
Bolt,1/4-20 x 1/2” Grade 8.2 Zinc SAE Flange Pkg of 50 3-30-2001-50
Y
Cap Screw, 1/4-20 x 1 1/2 Grade 8 Yellow Zinc Hex Head Pkg of 25 3-30-1119-25
Y
Cap Screw, 1/4-20 x 1/2 Grade 8 Yellow Zinc Hex Head Pkg of 50 3-30-1109-50
Y
Cap Screw, 1/4-20 x 3/4 Grade 8 Yellow Zinc Hex Head Pkg of 50 3-30-1113-50
Y
Cap Screw, 1/4-20 x 5/8 Grade 5 Zinc Hex Pkg of 100 3-30-1110-100
Y
Cap Screw, 5/16-18 x 1/2” Grade 5 Zinc Plated Hex Pkg of 50 3-30-1122-50
Y
Cap Screw,1/4-20 x 3/8” Grade 5 Zinc Hex Pkg of 25 3-30-1106-25
Y
Cap Screw,5/16”-18 x 3/4” Grade 8 Plain Finish Hex Pkg of 50 3-30-1126-50
Y
Dowel Pin, 3/16 x 2” Bright Finish Steel Pkg of 15 3-30-2005-15
Y
Lock Nut, 10-32 Grade A Zinc Plated Top Pkg of 100 3-30-8019-100
Y
Machine Screw, 1/4”-20 x 2 1/2” Phillips Round Head Zinc Pltd
Pkg of 25 3-30-6007-25
Y
Machine Screw, 10-32 x 3/8” Phillips Round Head Zinc Plated
Pkg of 100 3-30-6005-100
Y
Nut , Centerlock,1/4-20 Pkg of 50 3-30-8020-100
Y
Nut, Grade 5 Zinc Plated Finished Hex, 5/16”-18 Pkg of 100 3-30-8005-100
Y
Nut,1/4”-20 Zinc Plated Finished Hex Pkg of 100 3-30-8004-100
Y
Nut,1/4-20 Grade C Zinc Plated Top Lock Pkg of 50 3-30-8021-50
Y
Rivet, 1/8” Dia .032-.062” Grip Range AB4-1CLD AlumRvtStlMndrl
Pkg of 100 3-30-7900-100
Y
Screw, #10-24 x 3/8” Alloy Steel Black Oxide Button Head Cap
Pkg of 100 3-30-3011-100
Y
Screw, 5/16”-18 x 3/8” Alloy Steel Black Oxide Knurled Point SSS
Pkg of 25 3-30-2004-25
Y
Screw, BLK OX, HWH TCS 10-24X1/2 Pkg of 100 3-30-1101-100
Y
Screw, Hex Washer Slot T23 Zinc Thread Cutting ,1/4-20x5/8”
Pkg of 50 3-30-1111-50 Y
Screw,1/4”-20 x 3/8” Alloy Steel Black Oxide Button Head Cap
Pkg of 100 3-30-3014-100
Y
Washer, 5/16” Zinc Plated SAE Flat Pkg of 50 3-30-0205-50
Y

Harman TL 2.6 Specifications

General

Brand	Harman
Model	TL 2.6
Category	Wood stove
Language	English
