4
Remote Control: 24VAC (E1)
Flame Sensor (E4)
Temperature Sensor (E2)
Display Output: 24VAC (E7)
3A Fuse (F1)
Low Voltage R & C: 24VAC (E12,
E13)
Gas Valve & Safety Switches:
24VAC (E11)
High Voltage: 120VAC (E10)
Blower/Inducer (E6)
J
Ignitor (E3)
C
H
G
F
D
E
J
I
B
A
Integrated Control Board Layout (ICB)
