USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Page 17 of 36 MaxFlo VS Pump IS2303VSP2 Rev-B
5.4. Hayward Automation Control Wiring (Optional, for remote control of pump
speed)
Note: For software compatible Hayward controls only. Existing user interface wiring connection (if present)
should be unplugged and second terminal block connector should be used to make wiring connections shown
below.
Figure 5.4 1
The MaxFlo VS pump can communicate with and be controlled by Hayward pool controls such as OmniLogic™,
ProLogic®, E-Command® 4, and OnCommand®. Minimum software revision requirements: OmniLogic R1.0.0,
ProLogic 3.00, OnCommand 1.00, E-Command 2.65, E-Command 4 2.80, AquaLogic 2.65, and AquaPlus 2.65. To
determine Hayward control software revision, consult the appropriate Hayward pool control installation manual or visit
our website at www.haywardpool.com. Connection wire must be rated for a minimum of 300V, and may be up to 500
feet in length. Use removable 4-position terminal block connector for wiring connection to motor drive PCB, taking care
to note the wire colors and corresponding numbers next to the connectors. Terminal block must be installed with
screws facing up to ensure proper connection.
When communicating with OmniLogic, the HUA (Hayward Unique Address) is used for communication. For all Hayward
controls other than OmniLogic, the pump address must be set using the SW200 DIP switch on the drive PCB. To
determine which address should be used, consult the appropriate Hayward Pro Logic pool control installation manual,
or visit our website at www.haywardpool.com. Pump addresses are set according to the table below.
SW200 DIP SWITCH STATUS
PUMP ADDRESS #1 #2 #3 #4 #5
Pool Filte
r
OF
F
OF
F
OF
F
OF
F
OF
F
Aux 1 / Spa Filte
r
OF
F
ON OF
F
OF
F
OF
F
Aux 2 OF
F
OF
F
ON OF
F
OF
F
Aux 3 OF
F
ON ON OF
F
OF
F
Aux 4 OF
F
OF
F
OF
F
ON OF
F
Aux 5 OF
F
ON OF
F
ON OF
F
Aux 6 OF
F
OF
F
ON ON OF
F
Aux 7 OF
F
ON ON ON OF
F
Aux 8 OF
F
OF
F
OF
F
OF
F
ON
Aux 9 OF
F
ON OF
F
OF
F
ON
Aux 10 OF
F
OF
F
ON OF
F
ON
Aux 11 OF
F
ON ON OF
F
ON
Aux 12 OF
F
OF
F
OF
F
ON ON
Aux 13 OF
F
ON OF
F
ON ON
Aux 14 OF
F
OF
F
ON ON ON
Lights Button OF
F
ON ON ON ON
