USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Page 29 of 36 MaxFlo VS Pump IS2303VSP2 Rev-B
10.2. Parts Listing
Ref.
No.
Part No. Description Qty.
1A SPX2300DLS Strainer Cover Kit (Includes Strainer Cover, Lock-Ring, O-Ring) 1
1B SPX2300DLSB Strainer Cover Kit for Biguanide Sanitizers (Includes Strainer Cover, Lock-Ring,
O-Ring) NOT Pressure Testable
1
2 SPX2300Z4 Strainer Cover O-Ring 1
3 SPX2300M Strainer Basket 1
4 SPX2300AA Pump Strainer Housing with Drain Plugs 1
5 SPX4000FG Drain Plug with O-Ring 2
6 SPX2700ZPA
Hardware Pack (Includes 4 Housing Bolts, Seal-Plate Spacers & Square Nuts 1
7 SPX2300Z3PAK3 Diffuser Screws (3 Pack) 1
8 SX220Z2 Diffuser O-Ring 1
9 SPX2300B Diffuser 1
10 SPX2710CM Impeller 1
11 GMX600
Housing O-Ring 1
12 SPX2700SA Shaft Seal Assembly 1
13 SPX2300E Seal Plate 1
14 SPX3200Z5PAK4 Motor Bolt (4 Pack) 1
15 SPX2300G Motor Support with Base Mount Screws 1
16 SPX1600Z52 Motor Support Base Mount Screws 1
17 SPX2700UNKIT Union Connector Kit (Includes 2 Nuts, Connectors, Gaskets) 1
18 SPX3400DR4 Motor Drive Display Cover (Cover only) 1
- SPX3200LCD Digital Control interface assembly 1
- SPX3400DRKIT Wall Mount Kit 1
OPTIONAL
19 SPX2300GR Optional Riser Base Aligns with Sta-Rite® Dyna-Pro® 1
POWER END
SPX2303Z1VSPE Power end assembly (includes parts #7-14, motor and drive) 1
* WHISPERFLO is a registered trademark of Pentair Aquatic Systems, which is used herein for identification purposes
only. This is a retrofit base for existing WHISPERFLO pump installations. Pentair Aquatic Systems is not affiliated
with Hayward Pool Products.
