6.4. Menu Outline
1. Configuration Menu (see section 6.6 for basic product configuration)
a. Set Day and Time
b. Speed Selection
c. MAX Allowed Speed
d. MIN Allowed Speed
e. Prime Duration
f. Remote Control Mode
g. Low Temp Operation
h. Low Temp Setting
2. Timer Menu (see section 6.7 to program the 8 speeds with timer functions)
a. Rename Timer “X” (where “X” equals 1 through 8)
b. Pump Speed for Timer “X” (where “X” equals 1 through 8)
c. Start/Stop Time for Timer “X” (where “X” equals 1 through 8)
d. Choose Days for Timer “X” (where “X” equals 1 through 8)
3. Preset Speed Setup Menu (see section 6.8 to program the 4 preset speeds)
a. Speed “X” Name (where “X” equals 1 through 4)
b. Speed “X” Duration (where “X” equals 1 through 4)
c. Speed “X” Speed (where “X” equals 1 through 4)
4. Diagnostics Menu (see section 6.9 to view product diagnostic information)
a. Display Firmware Revision
b. Drive Serial Number
c. Motor Drive Firmware Revisions
d. DC Bus Voltage Status
e. Motor Current
f. Power Usage
g. Driver Temperature
h. Event Log (if applicable)
6.5. Initial startup
After plumbing and wiring are complete, the variable speed drive must be configured prior to use. When power is
applied to the drive for the first time, the following informational screens are displayed.
Screen Comments
1.
2.
3.
Note: Speeds can be selected at this time to temporarily run the pump, however, it is recommended that the drive
configuration and timers be set according to individual installation site requirements (see section 6.7 for more
details). At this point, pressing the MENU button will select the Configuration Menu.
Hayward Varia
le
Speed Pump
Thursday 1:27p
1725rpm 380 Watts
Timer 1 timer
will end at 11:45p
