6.6. Configuration Menu
Buttons
Screen Used Comments
1. < > Press & hold < and > buttons for several seconds to
unlock Configuration Menu
2.
< > Use > to enter Configuration Menu
3.
4.
+ - Use + to change clock setting
< > Use > if clock is correct
5.
+ - Adjust day/time setting
< > Move to next selection, then to next menu item
6.
+ - Select whether to display speed in rpm (Revolutions
per Minute) or % of full speed
< > Move to next menu item
7.
+ - Set maximum running speed of pump
< > Move to next menu item
8.
+ - Set minimum running speed of pump
< > Move to next menu item
9.
+ - Select pump prime duration
< > Move to next menu item
Note: User may set the pump to prime at the maximum allowed speed for 0-15 minutes in 30 second increments.
10.
+ - Select Stand Alone or Relay Control
< > Move to next menu item
Note: See section 5.3 for more detail.
11.
+ - Enable or Disable Low Temp Operation
< > Move to next menu item
12.
+ - Set temperature to activate Low Temp Operation
< > Move to next menu item
Note: When the pump is stopped and the ambient temperature drops below the operation temperature set point,
the pump will prime and then run at the MAX allowed speed setting for 8 hours. Low temperature operation is
not
active when the pump is being remotely controlled. Low temperature operation is NOT intended to protect the
Configuration Menu
press > to enter
Set Day and Time
Thursday 1:27p
Speed Selection
rpm
MAX allowed spee
d
3450 (600-3450rpm)
MIN allowed spee
d
600 (600-3450rpm)
Prime Duration
8:00 minutes
Remote Control Mode
Stand Alone
Configuration Menu
Locked
Time: Th 1:27PM
+ change or > skip
Use + / - to adjust,
> go to next item
Low Temp Operation
Disabled
Low Temp Setting
4ºC (39.2ºF)
