Surface mounting: The Probe Cell can be mounted up to 15' away from the OmniLogic (limited by
length and routing of cable). Use the four mounting holes on the back of the bracket when surfac-
ing mounting. Common wood screws can be used for most applications.
Plumbing the Probe Cell to the pool plumbing
The Probe Cell requires connection to the pool plumbing using the supplied flex tubing. Two ports
on the Probe Cell, influent and effluent, are connected to the supply and return sides of the pool
plumbing. Refer to diagram on th following page as well as the instructions.
