Drive track removed Track idler pulley (2/side)
Note that flange faces inward.
Drive Track & Idler Pulley Removal
Drive Side
Page 13
Bearings should rotate smoothly
and freely.
Check for missing/broken drive
cogs on inner loop of belt and also
for cracks in belt.
