Thermal Image Scope User Manual
22
Chapter 7 Measure Distance
The device can detect the distance between the target and the observation position.
Before You Start
When measuring the distance, keep the hand and the position steady. Otherwise, the accuracy
may be affected.
Steps
1. Hold to show the menu.
2. Select and press to go to the setting interface.
1) Press or to select the target from Deer, Grey Wolf, Brown Bear, and Custom.
2) Set the target height.
Note
The available height ranges from 0.1 m to 9.9 m.
3) Press to confirm.
3. Align the center of top mark with the edge of target top. Press .
The cursor blinks on the top edge of the target.
4. Align the center of bottom mark with the edge of target bottom. Press .
Result
The left top of the image displays the distance measurement result and the height of the target.
Figure 7-1 Measurement Result
Note
Go to distance measurement interface, and press to view the result of the previous
measuring target.
