User Manual of E Series Network Mini PTZ camera
© Hikvision
42
 Up to 8 NAS disks can be connected to the mini PTZ camera.
 To initialize and use the SD card after insert it to the mini PTZ camera, please refer to the
steps of NAS disk initialization.
5.2 Basic Event Configuration
Purpose:
This section explains how to configure the network mini PTZ camera to respond to alarm events,
including motion detection, video tampering and exception. These events can trigger the alarm
actions, such as Notify Surveillance Center, Send Email, Trigger, etc.
For example, when motion detection is triggered, the network mini PTZ camera sends a
notification to an e-mail address.
On the event configuration page, click to show the PTZ control panel or click to hide it.
Click the direction buttons to control the pan/tilt movements.
Click the zoom/iris/focus buttons to realize lens control.
5.2.1 Configuring Motion Detection
Purpose:
Motion detection is a feature which can trigger alarm actions and actions of recording videos
when the motion occurred in the surveillance scene.
Steps:
1. Enter the motion detection setting interface:
Configuration > Event > Basic Event > Motion Detection
2. Check the checkbox of the Enable Motion Detection to enable this function.
You can check the Enable Dynamic Analysis for Motion checkbox if you want the detected
object get marked with rectangle in the live view.
3. Select the configuration mode as Normal or Expert and set the corresponding motion
detection parameters.
 Normal
