HIKVISION DS-2SE7C43C432MW-AEB User Manual

Steps
1.
Go to VCA → Smart Event → Region Entrance Detecon .
2.
Select a channel.
3.
Check Enable.
4.
Oponal: Click Lock to lock PTZ control to prevent the interrupon from other PTZ related acon
during conguraon.
Normally, the PTZ control is automacally locked when you enter the conguraon interface.
You can manually resume the lock when the countdown is over.
5.
Adjust the live image to the desired scene by using PTZ control
buons.
Note
PTZ control is only available for Camera 01.
6.
Draw detecon area.
1) Select a Region No.. Up to 4 regions can be set.
2) Click
Detecon Area.
3) Click on the live image to draw the boundaries of the
detecon area, and right click to
complete drawing.
7.
Oponal: Set the minimum size and the maximum size for the target to improve detecon
accuracy. Only targets whose size are between the maximum size and the minimum size trigger
the detecon.
1) Click Max. Size, and drag the mouse on live image. If you want to change the size, click the
buon and draw again.
2) Click Min. Size, and drag the mouse on the live image. If you want to change the size, click the
buon and draw again.
8.
Set detecon parameters.
Sensivity
It stands for the sensivity of detecng an target. The higher the value is,
the more easily the target is detected.
Detecon
Target
You can specify the object type, and the device only detects the selected
type of objects.
TandemVu PTZ Camera User Manual
64

HIKVISION DS-2SE7C43C432MW-AEB Specifications

General

Camera Type	PTZ
Image Sensor	1/2.8" progressive scan CMOS
Max. Resolution	2560 × 1440
Digital Zoom	16x
Presets	300
Video Compression	H.265+/H.265/H.264+/H.264/MJPEG
Ingress Protection	IP67
Day/Night	IR Cut Filter
Noise Reduction	3D DNR
Effective Pixels	2560 × 1440
Min. Illumination	Color: 0.005 Lux @(F1.5, AGC ON)
Supplement Light Range	Up to 150 m
Pan Range	360°
Tilt Range	–15° to 90°
Pan Speed	0.1°–300°/s
Bit Rate	32 Kbps to 16 Mbps
Audio Compression	G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM
Network Interface	RJ45 10/100 Mbps Ethernet
Ethernet	10/100 Mbps
Protocols	IPv4/IPv6, HTTP, HTTPS, FTP, SMTP, UPnP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Alarm Interface	1 input, 1 output
Audio Interface	1 input, 1 output
Audio Input	1
Audio Output	1
On-board storage	Built-in microSD/SDHC/SDXC slot, up to 256 GB
Power Supply	24 VAC
Power	AC 24 V
Operating Conditions	-40°C to 70°C (-40°F to 158°F), Humidity 95% or less (non-condensing)
Operating Temperature	–40 °C to 70 °C
Protection Level	IP67
Wide Dynamic Range	120 dB
Zoom Speed	Approx. 4.8 s (optical, wide-tele)
Tilt Speed	Configurable, from 0.1°/s to 150°/s
