DS-2TD2xxx-xx/xx Thermal and Optical Bi-Spectrum Network Bullet Camera Quick Start Guide
QSG DS-2TD2xxx-xx/xx 071720NA 11
Sun Shield
Camera
Bracket Holder
Bracket Hinge
Junction Box Base
Cable Outlet
Memory Card Slot
Reset Button
Junction Box Cover
Sealing Interface
Bracket Arm
Figure 7, Type III Camera Cables
Type IV Camera Appearance
Bracket
Sun Shield
Thermal Lens
Optical Lens
Reset Button
Memory Card
Slot
White Light
Lamp
Speaker
Figure 8, Type IV Camera Appearance
Cable Description
The bullet camera cables, including power cable, alarm cable, and audio cable are shown as figure below.
The cable is provided for certain camera models. Refer to the actual device.
