User Manual of Digital Video Recorder
113
9.2.4 Configuring UPnP™
Purpose:
UPnP™ can permits the device seamlessly discover the presence of other network devices on the network and
establish functional network services for data sharing, communications, etc. If you want to use the UPnP™
function to enable the fast connection of the device to the WAN via a router, you should configure the UPnP™
parameters of the device.
Before you start:
If you want to enable the UPnP™ function of the device, you must enable the UPnP™ function of the router
to which your device is connected. When the network working mode of the device is set as multi-address, the
Default Route of the device should be in the same network segment as that of the LAN IP address of the
router.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the UPnP tab to enter the UPnP™ interface.
Figure 9. 16 UPnP™ Settings Interface
3. Check checkbox to enable UPnP™.
4. Select the mapped type to Auto or Manual.
When you select Auto, the mapping ports can be automatically assigned by the router. When you select
Manual, you should continue Step5 to edit the mapping ports.
5. Click to open the External Port Settings dialog box. Configure the external port No. for server port,
HTTP port and RTSP port respectively.
You can use the default port No., or change it according to actual requirements.
External Port indicates the port No. for port mapping in the router.
Figure 9. 17 External Port Settings Dialog Box
