User Manual of Digital Video Recorder
31
4. On the pop-up message box, click Yes to restart the device to enable the CVBS output as the main output.
You can select the Menu Output Mode under Menu > Configuration > General > More Settings to Auto or
HDMI/VGA and then restart the device to switch the main output back to VGA output.
3.2.3 Quick Setting Toolbar in Live View Mode
On the screen of each channel, there is a quick setting toolbar which shows when you right-click mouse on the
camera.
Figure 3. 4 Quick Settings Toolbar
Table 3.3 Description of Quick Setting Toolbar Icons
Instant Playback
Instant Playback only shows the record in last five minutes. If no record is found, it means there is no
record during the last five minutes.
Digital Zoom
Digital Zoom can zoom in the selected area to the full screen. You can left-click and draw to select the
area for zooming in, as shown in Figure 3.5.
