User Manual of Digital Video Recorder
19
2.1 Starting Up and Shutting Down the
Device
Purpose:
Proper startup and shutdown procedures are crucial to expanding the life of the device.
Before you start:
Check that the voltage of the extra power supply is the same with the device’s requirement, and the ground
connection is working properly.
Starting up the device:
Check the power supply is plugged into an electrical outlet. It is HIGHLY recommended that an
Uninterruptible Power Supply (UPS) be used in conjunction with the device.
For the DS-7100 series DVR, insert the power supply plug into the power connector on the rear panel and the
device will start up; and for the DS-7200 series DVR, turn on the power switch button on the rear panel after
the power supply is connected. The Power indicator LED should turn red indicating that the device begins to
start up.
Shutting down the device:
Steps:
1. Enter the Shutdown menu.
Menu > Shutdown
Figure 2. 1 Shutdown Menu
2. Click the Shutdown button to enter the following dialog box:
Figure 2. 2 Dialog Box for Shutdown
3. Click the Yes button. The following message box pops up:
Figure 2. 3 Message Box for Power Off
4. For the DS-7100 series DVR, disconnect the power supply plug on the rear panel, and for the DS-7200
series DVR, turn off the power switch button on the rear panel.
Rebooting the device
In the Shutdown menu (Figure 2.1), you can also click Reboot to reboot the device.
