HIKVISION DS-96256NI-I24 User Manual

Network Video Recorder User Manual
184
13.4 Managing HDD Group
13.4.1 Setting HDD Groups
Purpose:
Multiple HDDs can be managed in groups. Video from specified channels can be recorded onto a particular HDD
group through HDD settings.
Steps:
1. Enter the Storage Mode interface.
Menu > HDD > Advanced > Storage Mode
2. Set the Mode to Group, as shown in Figure 13. 11.
Figure 13. 11 Storage Mode Interface
3. Click the Apply button and the following Attention box will pop up.
Figure 13. 12 Attention for Reboot
4. Click the Yes button to reboot the device to activate the changes.
5. After reboot of device, enter the HDD Information interface.
Menu > HDD> General
6. Select HDD from the list and click icon to enter the Local HDD Settings interface, as shown in Figure
13. 13.
Figure 13. 13 Local HDD Settings Interface

HIKVISION DS-96256NI-I24 Specifications

General

Brand	HIKVISION
Model	DS-96256NI-I24
Category	Network Hardware
Language	English
