HIKVISION DS-K1T105E-C User Manual

Access Control Terminal·Quick Start Guide
37
Enable the Wiegand: Select whether to enable the Wiegand.
Click the # key to enable first card.
Wiegand Mode: The default Wiegand mode is Wigand 34.
 Click the key to enter and exit the editing mode.
 Click the Right/Left direction keys to choose contents.
 Click the # key to switch the mode between “Yes” mode and “No” mode.
4. Move the cursor to the OK button, and click the # key.
6.2.4 Wi-Fi Settings
Steps:
1. Move the cursor to Wi-Fi (Wi-Fi settings) by using direction keys on the
communication settings interface.
2. Click the # key to enter the Wi-Fi settings interface.
Figure 6-17 Wi-Fi Enabling
3. Move the cursor to and click the # key to enable the WLAN.

HIKVISION DS-K1T105E-C Specifications

General

Brand	HIKVISION
Model	DS-K1T105E-C
Category	IP Access Controllers
Language	English
