Hirschmann EAGLE20 series User Manual

16
Installation EAGLE20/30
Release 06 04/2014
1.2 Device name and product code
The device name corresponds to the product code. The product code is
made up of characteristics with defined positions. The characteristic values
stand for specific product properties.
Item Product
characteristic
Character
istic value
Description
1 ... 7 Device EAGLE20 Router without gigabit ports
EAGLE30 Router with gigabit ports
8 (hyphen) –
9 ... 10 Number:
Fast ethernet ports
04 4 × Fast ethernet ports
11 ... 12 Number:
Gigabit ethernet ports
00 0 × Gigabit ethernet ports
02 2 × Gigabit ethernet ports
13 ... 15 Configuration of the
uplink ports
2O6 2 × SFP slot
999 Not present
16 ... 17 Configuration of the
other ports
TT All the other ports are RJ45 sockets for twisted
pairs
18 Cellular phone
interface
9 Not present
19 ... 20 WAN port 99 Not present
21 Temperature range S Standard 0 °C ... +60 °C (+32 °F ...
+140 °F)
T Extended −40 °F ... +158 °F (−40 °C
... +70 °C)
E Extended with
conformal coating
−40 °F ... +158 °F (−40 °C
... +70 °C)
22 Operating voltage C Voltage input
Rated voltage range DC
24 V ... 48 V
K Voltage input
Rated voltage range AC
110 V ... 230 V, 50 Hz ... 60 Hz
Rated voltage range DC
60 V ... 250 V
23 Operating voltage C Voltage input
Rated voltage range DC
24 V ... 48 V
9 Not present
24 ... 25 Certifications Note: You will find detailed information on the certificates
and declarations applying to your device in a separate
overview.
See table 3 on page 18.
Table 1: Device name and product code
