Installation EAGLE20/30
Release
06
04/2014
29
2.3 Installing and grounding the device
2.3.1 Installing the device onto the DIN rail
Note: Verify that there is at least 4 in (10 cm) of space above and below the
device.
Note: The overall shield of a connected shielded twisted-pair cable is
connected to the ground connector on the front panel as a conductor.
To mount the device onto a horizontally mounted 35 mm DIN rail according
to DIN EN 60715, proceed as follows:
Slide the upper snap-in guide of the device into the DIN rail.
Pull down the locking gate using a screwdriver, and press the lower part
of the device against the DIN rail.
Snap in the device by releasing the locking gate.
WARNING
FIRE HAZARD
Install the device in a fire protected enclosure according to EN 60950-1.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
WARNING
Solely for device variants featuring working voltage with the characteristic
value K:
ELECTRIC SHOCK
Install this device solely in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
