signal source entry
other equipment
36
Press the MENU button. The MAIN
MENU appears.
Press the cursor DOWN button to
select INSTALL.
Once highlighted, accept selection.
Press the cursor DOWN button to
select MANUAL SETUP.
Once highlighted, accept selection.
Use the UP/DOWN cursor keys to
select the programme you wish to use and
the LEFT/RIGHT cursor keys to move the
selection bar over the AV required to be adjusted.
Select your method of signal source
entry using the UP/DOWN cursor buttons.
option 1
AV1 is the signal source used when connecting a
VCR through a scart lead to the AV1 socket at the rear of your TV. For convenience,
programme 0 is best used for your VCR.
1
2
3
4
5
6
8
...notes on signal source entry
Each piece of external equipment connected to your TV must have its own input socket. It would also be easier, and more
organized, if the external equipment connected also had its own programme number. Signal Source entry allows you to tell the
allocated program what equipment is connected to which socket. This would make the switching between normal operation and
the connected equipment much smoother.
For example, if you want to connect a games machine to your TV -
1. connect to socket AV2 via a scart lead.
2. give your games machine an empty programme number of its own.
3. if desired change this programme name.
4. give this programme the correct AV signal source.
Once highlighted, accept selection.
7
