Hitachi 43FDX10B User Manual

11
Model: 43FDX10B 53UDX10B
43FDX11B 61UDX10B
Cathode-Ray Tube:
53UDX10B/61UDX10B R=P16LFM00RFA(TU)
G=P16LFM00HHA(TU)
B=P16LFM00BMB(TU)
43FDX10B/43FDX11B R=P16LTG00RFA
G=P16LTG00HHA
B=P16LTG00BMB
Power Input: 120 volts AC, 60 Hz
Power Consumption:
¥ Stand-By Power
43FDX10B/43FDX11B . . . . . . . . . . . . .2.7W
53UDX10B/61UDX10B . . . . . . . . . . . . .2.7W
¥ Power Consumption (operating)
43FDX11B/43FDX10B . . . . . . . . . . . . .225W
53UDX10B/61UDX10B . . . . . . . . . . . .216W
¥ Power Consumption (maximum)
43FDX11B/43FDX10B . . . . . . . . . . . . .265W
53UDX10B/61UDX10B . . . . . . . . . . . .253W
Antenna Impedance: 75 Ohm Unbalanced
VHF / UHF / CATV
Receiving Channel: BAND CH
VHF 2~13
UHF 14~69
EXT. Mid (A-5)~(A-1), 4+
CATV Mid. A~I
CATV Super J~W
CATV Hyper (W+1)~(W+28)
Intermediate Frequency: Picture l-F Carrier 45.75 MHz
Sound l-F Carrier 41.25 MHz
Color Sub Carrier 42.17 MHz
Video Input: 1 Volt p-p, 75 Ohm
Video Output: 1 Volt p-p, 75 ohm
Audio Input: 470 mVrms, 47 k Ohm
Stereo Audio Output: 470 mVrms, 1 k Ohm
Audio Output Power:
Front: 12 watts per channel at 10% distortion,
8 ohm Impedance. Max output Ð 15 watts.
Anode Voltage:
30.2±0.2kv (1.32±0.2mA)
Brightness: 43 53 61
(white screen) 250cd/m
2
170cd/m
2
150cd/m
2
Speakers: 2 Woofers - 5 inch (120 mm) round
2 Tweeters - 2 inch (50 mm) round
Dimension:
43Ó 53Ó 61Ó
Height (in.) 43
5
/
8
51
5
/
8
61
1
/
8
Width (in.) 38
15
/16 46 52
3
/
8
Depth (in.) 20
1
/
16
25
5
/
16
28
7
/
8
Weight (Ibs.) 148 225 283
Circuit Board Assemblies:
C.P.T. (B) P.W.B. Terminal A P.W.B.
C.P.T. (G) P.W.B. Terminal B P.W.B.
C.P.T. (R) P.W.B. VM P.W.B.
Audio Out P.W.B. Surround P.W.B.
2H P.W.B. Power Deflection P.W.B.
Power Supply P.W.B. Control P.W.B.
Signal P.W.B. Control Sub P.W.B.
Convergence P.W.B. Sensor Distribution P.W.B.
CIRCUIT PROTECTION
CAUTION: Below is an EXAMPLE only. See Replacement Parts List for details. The following symbol near the fuse
indicates fast operation fuse (to be replaced). Fuse ratings appear within the symbol.
125V
5A
F
5 A 125V
Example:
SPECIFICATIONS
RISK OF FIRE - REPLACE FUSE AS MARKED
The rating of fuse F901 is 5A - 125V.
Replace with the same type fuse for continued protection
against fire.
