Quick Reference Parts List
NO. CIRC. # PART NO. DESCRIPTION PWB ASS’Y FUNCTION
1 I001 CP07166U MAIN MICRO SIGNAL TV u-com "HZ"
2 I002 CP06941R PST9941 SIGNAL RESET IC (+3.3V)
3 I003 CK35894R CAT24WC32J1 SIGNAL E2PROM
4 I004 CK09541R HD74HCT245T SIGNAL 3.3V->5.0V BUFFER
5 I005 CK31992R BU4053BCF-E2 SIGNAL MAIN/SUB SELECTOR
6 I006 CK31071R CXA1875AM SIGNAL EXT DAC1
7 I007 CK31071R CXA1875AM SIGNAL EXT DAC2
8 I301 CK09013U UPD64082GF-3BA SIGNAL 3D Y/C SEP.
9 I302 CK06097R PST9127NR SIGNAL RESET IC FOR I301
10 I303 CK35321R MSM514265E-60J3 SIGNAL 4M DRAM FOR I301
11 I501 CK07923U TA1270BF SIGNAL MAIN VIDEO/CHROMA
12 I502 CK35501R NJM2284M-TE1 SIGNAL VIDEO SWITCH
13 I503 CK01172R HD74HC221FP-TR SIGNAL S PULSE GENERATOR
14 IC01 CP07281U TA1316AN SIGNAL RGB PRO./DEF CONT.
15 IC02 CP07611 NJM7805FA SIGNAL SW +5V REG
16 IC03 CP04232 BA033T SIGNAL SW +3.3V REG
17 IC04 CP06581U LF25CV SIGNAL SW +2.5V REG
18 IJ01 2004751 TA8200AH SIGNAL FRONT AUDIO OUT
19 IX01 CK30941U CXA2069Q TERMINAL A/V SELECTOR
20 IX02 CW00022 UGL-337KNT TERMINAL 2L COMB FOR SUB
21 IX03 CK07923U TA1270BF TERMINAL VIDEO/CHROMA FOR SUB
22 IX04 CK35371U CXA2151Q TERMINAL YPBYR SEL. FOR MAIN
23 IX05 CK35371U CXA12141Q TERMINAL YPBYR SEL FOR SUB
24 IX06 CK31992R BU4053BCF-E2 TERMINAL HOR. SYNC SEL
25 IX07 CK31992R BU4053BCF-E2 TERMINAL VER. SYNC SEL.
26 IX08 2015452R HD74HC04FPEL TERMINAL INVERTER
27 IX09 CK01172R HD74HC221FP-TR TERMINAL YS PULSE GENERATOR
28 I601 CP06891 TDA8174A DEFLECTION VER. DEF OUTPUT
29 I701 2352505 NJM4558D DEFLECTION GAIN AMP
30 IH01 CP07091 M62501P DEFLECTION HIGH VOLTAGE CONT.
31 IP01 CZ00865 STR-F6629B (LF1351) DEFLECTION SWITCHING REGULATOR IC
32 IP02 CP05431 TLP621(D4-GRL-LF2) DEFLECTION OPT. ISOLATOR
33 IP03 2391343 SE115N DEFLECTION +B REGULATOR IC
34 IP04 2004665F PQ09RF2B DEFLECTION +9V REGULATOR
35 IP05 2004666F PQ05RF2B DEFLECTION +5V REGULATOR
36 IP06 CP06141 PQ6RD083 DEFLECTION +6.V REGULATOR
37 I901 CP07821U STR-G6632 POWER SWITCHING REGULATOR IC
38 I901 CP07823U STR-G6623 POWER SWITCHING REGULATOR IC
39 I902 CP05431 TLP621(D4-GRL-LF2) POWER OPT. ISOLATOR
40 I903 CP05431 TLP621(D4-GRL-LF2) POWER OPT. ISOLATOR
41 I904 CP05431 TLP621(D4-GRL-LF2) POWER OPT. ISOLATOR
42 I906 CP07614 NJM7809FA POWER +9V REGULATOR
43 IK01 CP07611 HNM7805FA CONV./FOCUS +5V REGULATOR
44 IK02 CP01531R PST9142-T CONV./FOCUS RESET IC FOR DCU
45 IK04 CZ00432 STK392-120 CONV./FOCUS CONV. AMP.
46 IK05 CZ00432 STK392-120 CONV./FOCUS CONV. AMP.
47 IA01 CK35262R NJW1132AM TRUS/SRS VOLUME CONT. W/ BBE
48 IA02 CK35451R NJM2198M TRUS/SRS SRS
49 EANT HP00771 ANT SW BOX MAIN CHASSIS ANT SW BOX
50 U501 HC00511 ENGE6106D SIGNAL 1ST TUNER W/MTS
51 U502 HC00462 ENG36614G SIGNAL 2ND TUNER
52 UC01 CS00493 HC5613 SIGNAL FLEX CONTROLLER
53 UKDG CS00453 HC2153 CONV./FOCUS DCU (MAGIC-S/9P)
54 HM01 CZ00641 GP1U281Q CONTROL I/R RECEIVER
