Hitachi 43FDX10B User Manual

119
SYMBOL PART PART SYMBOL PART PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION
CAPACITOR C038 0800326R CAP.-ELECTRO. 100UF-M 16V
C001 0800326R CAP.-ELECTRO. 100UF-M 16V C041 0800326R CAP.-ELECTRO. 100UF-M 16V
C002 0893232R CAP 1608CHIP 100000PFZF25V TAPE C042 0893232R CAP 1608CHIP 100000PFZF25V TAPE
C003 0800326R CAP.-ELECTRO. 100UF-M 16V C043 0893239R CAP 1608CHIP 10000PFZF 50V TAPE
C004 0893232R CAP 1608CHIP 100000PFZF25V TAPE C044 0893232R CAP 1608CHIP 100000PFZF25V TAPE
C005 0800326R CAP.-ELECTRO. 100UF-M 16V C045 0800326R CAP.-ELECTRO. 100UF-M 16V
C006 0800326R CAP.-ELECTRO. 100UF-M 16V C046 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V
C007 0893232R CAP 1608CHIP 100000PFZF25V TAPE C047 0800318R CAP.-ELECTRO. 47UF-M 25V
C008 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V C048 0800318R CAP.-ELECTRO. 47UF-M 25V
C009 0893119R CAP 1608CHIP 33PFJCH 50V TAPE C049 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V
C010 0893119R CAP 1608CHIP 33PFJCH 50V TAPE C050 0893232R CAP 1608CHIP 100000PFZF25V TAPE
C011 0893118R CAP 1608CHIP 27PFJCH 50V TAPE C051 0893213R CAP1608CHIP 2200PFKB 50V TAPE
C012 0893118R CAP 1608CHIP 27PFJCH 50V TAPE C052 0800328R CAP. ELECTRO. 100UF-M 35V
C013 0893216R CAP 1608CHIP 3900PFKB 50V TAPE C053 0800326R CAP.-ELECTRO. 100UF-M 16V
C014 0893239R CAP 1608CHIP 10000PFZF 50V TAPE C054 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C015 0800326R CAP.-ELECTRO. 100UF-M 16V C055 0800326R CAP.-ELECTRO. 100UF-M 16V
C016 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V C056 0893232R CAP 1608CHIP 100000PFZF25V TAPE
C017 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V C057 0893239R CAP 1608CHIP 10000PFZF 50V TAPE
C018 0893208R CAP 1608CHIP 1000PFKB 50V TAPE C060 0800326R CAP.-ELECTRO. 100UF-M 16V
C019 0800319R CAP.-ELECTRO. 47UF-M 35V C061 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C023 0893205R CAP 1608CHIP 560PFKB 50V TAPE C064 0893232R CAP 1608CHIP 100000PFZF25V TAPE
C024 0893239R CAP 1608CHIP 10000PFZF 50V TAPE C065 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C025 0893128R CAP 1608CHIP 150PFJCH 50V TAPE C071 0893125R CAP 1608CHIP 82PFJCH 50V TAPE
C026 0893126R CAP 1608CHIP 100PFJCH 50V TAPE C072 0893125R CAP 1608CHIP 82PFJCH 50V TAPE
C027 0893232R CAP 1608CHIP 100000PFZF25V TAPE C073 0893125R CAP 1608CHIP 82PFJCH 50V TAPE
C028 0800326R CAP.-ELECTRO. 100UF-M 16V C074 0893205R CAP 1608CHIP 560PFKB 50V TAPE
C029 0893232R CAP 1608CHIP 100000PFZF25V TAPE C075 0893205R CAP 1608CHIP 560PFKB 50V TAPE
C030 0893232R CAP 1608CHIP 100000PFZF25V TAPE C1A1 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V
C031 0893133R CAP 1608CHIP 330PFJCH 50V TAPE C1A2 0800326R CAP.-ELECTRO. 100UF-M 16V
C032 0800318R CAP.-ELECTRO. 47UF-M 25V C301 0800294R CAP.-ELECTRO. 10UF-M(SMG) 50V
C034 0893232R CAP 1608CHIP 100000PFZF25V TAPE C302 0893239R CAP 1608CHIP 10000PFZF 50V TAPE
C035 0893133R CAP 1608CHIP 330PFJCH 50V TAPE C303 AA01101R CERAMIC CAPACITOR(1UF 10V-F)
C036 0800318R CAP.-ELECTRO. 47UF-M 25V C304 0800279R CAP.-ELECTORO. 1.0UF-M(SMG) 50V
REPLACEMENT PARTS LIST
PRODUCT SERVICE NOTE: Components marked with a have special characteristics important to safety. Before replacing
any of these components, read carefully, the PRODUCT SAFETY NOTICE of this Service Manual. DonÕt degrade the safety of the
receiver through improper servicing.
!
Capacitors: Resistors: Semiconductors:
AL: Aluminum Electrolytic CF: Carbon Film TR: Transistor
CD: Ceramic Disc CC: Carbon Composition DI: Diode
EL: Electrolitic MF: Metal Oxide ZD: Zener Diode
PF: Polyester Film VR: Variable Resistor VA: Varistor
PP: Polypropylene WW: Wire Wound TH: Termistor
PL: Plastic FR: Fuse Resistor IC: Integrated Circuit
TA: Tantalum MG: Metal Grazed
PR: Paper
TM: Trimmer
MC: Mylar
ABBREVIATIONS
