Hitachi 43FDX10B User Manual

46
Parameter Normal
ADJ. DISP 77 ¥
SEL. STAT 00 ¥
DEMO WAIT 2F ¥
INT STEP 1 02 ¥
INT A DLY 0A ¥
INT C DLY FA ¥
INT BAR 1C ¥
MGF STEP 1 00 ¥
MGF A DLY 0A ¥
MGF C DLY FA ¥
MGF BAR 0E ¥
SENSOR CK 00 ¥
SENSOR 0 FF ¥
SENSOR 1 00 ¥
SENSOR 2 FF ¥
SENSOR 3 01 ¥
SENSOR 4 FF ¥
SENSOR 5 06 ¥
SENSOR 6 FF ¥
SENSOR 7 07 ¥
AD LEVEL 03 ¥
E. DISPLAY 00 ¥
ADJ. TIMS 60 ¥
AD LEVEL 05 ¥
AD NOISE 80 ¥
PHASE MOT 60 ¥
H. BLK-RV 06 03
H. BLK-GV 01 ¥
H. BLK-BV 06 03
H. BLK-H 00 ¥
PON DELAY 0c ¥
IR-CODE 00 ¥
INITIAL 50 9E ¥
MGF 50 96 ¥
9 POINT 50 FE ¥
STAT 50 FE ¥
DYNA 50 9F ¥
1080i
Through
2.12.1 MAGIC FOCUS Character Set-Up
This instruction should be applied when a new DCU
is being replaced.
Adjustment Preparation
(1) Receive NTSC RF or video signal.
(2) With Power off, PRESS and HOLD the SERVICE
ONLY button on CONVER/FOCUS PWB, then press
the Power On/Off, when picture appeares release
SERVICE ONLY switch. (Internal crosshatch is
displayed without conv. correction data.)
Adjustment Procedure
(1) Press FREEZE key on R/C. (One additional line
appears near the top and near the bottom.)
(2) Press PIPCH key, then ADJ. PARAMETER mode is
displayed as following.
(3) Press F or E key to change the ADJ. DISP. data.
(4) Press CURSOR H to access DCU parameter.
Change the data as shown on Table 1, DCU
Parameter.
ADJ. PARAMETER
ROM WRITE?
R ADJ. DISP. : 77
SEL. STAT. : 00
DEMO.WAIT : 2f
NORMAL MODE
TABLE 1. - DCU PARAMETER
