4-1. Selling Point Descriptions
(1) Laser guide system (Only the Model C 10FCH2)
Use the laser marker for aligning with the ink line on the
workpiece.
Cutting position can be properly adjusted by aligning the
positioning ink line with the laser line. There is no need to
make a long ink line on the workpiece.
There is no need to lower the motor head to align with the
ink line because the laser marker makes a laser line on the
workpiece. In addition, cutting position can be easily
adjusted because the operator can hold the workpiece with
both hands to move.
Cutting poisition can be easily adjusted because the laser
line can be aligned with an optionally angled ink line.
Even the woekpieces such as crown moldings and base
boards that have decorative surfaces and are difficult to be
made an ink line can be cut just by aligning the laser line
with the ink line on the fence side. The laser line is adjusted
to the width of the saw blade at the time of factory shipment.
Depending upon the user's cutting choice, the laser line can
be aligned with the left side of the cutting width (saw blade)
or the ink line on the right side. Adjust the position of the
laser line according to "8-1. Position Adjustment of Laser
Line" on page 11.
(2) Aggressive tool design
The tool color is gunmetallic silver to give a sturdier image. The circular saw portion is of a powerful, original
and aggressive design.
(3) Soft, vibration reducing grip
The handle grip is comfortable and slip-resistant thanks to the integrally molded rubber. In addition, it reduces
vibration transmitted to the operator's hand. The Models C 10FCH2 and C 10FCE2 are easier to operate.
(4) Lightest weight in 10" class
The Model C 10FCH2 weighs 12 kg (26.5 lbs.) and the Model C 10FCE2 weighs 11.9 kg (26.2 lbs.)
The Models C 10FCH2 and C 10FCE2 are the lightest compound miter saws in the 10" class.
1
2
3
4
Fig. 1
Fig. 2
Laser line
Ink line
Laser beam
