– 6 –
TANK UNIT
OUTDOOR UNIT
PREPARATION
Hot water outlet (G 3/4"B)
Control panel
Leak water receiver
Cold water inlet (G 3/4")
Mg-Anode
When heating operation, drain or
defrosted water flows out from
outdoor unit.
Don’t close drain outlet portion in
chilly area so as not to freeze these.
CAUTION
Refrigerating pipe
Air inlet (back and left side)
Air outlet
Condensed water outlet
NAME OF EACH PART
Note:
– Mg-Anode should be changed yearly, it may loose its function
for corrosive protection if exceeds the time frame.
– It is recommended to replace the Mg-Anode every 1 year
depends on the quality of water.
– Type number for Mg-Anode is <SPX-WTA1>. Use this number
for ordering when wants to replace.
