/dev/sdu -> CHNO = 0 TID = 1 LUN = 14
[[SQ] CL2-G Ser = 63528 LDEV =2755 [HITACHI ]
[OPEN-V ]
HORC = SMPL HOMRCF[MU#0 = SMPL MU#1 = SMPL MU#2 =
SMPL]
E-LUN[Group 00001] SSID = 0x000B
SNAPS[PoolID 0001] SSID = 0x000B
/dev/sdv -> CHNO = 0 TID = 1 LUN = 15
[[SQ] CL2-G Ser = 63528 LDEV =2768 [HITACHI ]
[OPEN-V ]
HORC = SMPL HOMRCF[MU#0 = SMPL MU#1 = SMPL MU#2 =
SMPL]
E-LUN[Group 08191] SSID = 0x000B
UNMAP[Group 00000] SSID = 0x000B
/dev/sdw -> CHNO = 0 TID = 1 LUN = 16
[[SQ] CL2-G Ser = 63528 LDEV =2769 [HITACHI ]
[OPEN-V ]
HORC = SMPL HOMRCF[MU#0 = SMPL MU#1 = SMPL MU#2 =
SMPL]
E-LUN[Group 16384] SSID = 0x000B
E-LUN[Group 16384] SSID = 0x000B
• Group: This item shows physical position of an LDEV according to
mapping of LDEV in the RAID storage system.
LDEV Mapping Display Formats
RAID Group RAID1[Group Group number - Sub number]
RAID5[Group Group number - Sub number]
RAID6[Group Group number - Sub number]
Copy-on-Write Snapshot S-VOL SNAPS[PoolID poolID number ]
Unmapped UNMAP[Group 00000]
External LUN E-LUN[Group External Group number]
Relations between "cc" command issues and status
The migration volumes can be handled by issuing the CCI commands (pair
creation and pair splitting commands). The validity of the specified operation
is checked according to the status of the paired volume (primary volume).
Table 6-12 Command issues and pairing status transition on page 6-42
shows the relations between the migration volume statuses and command
acceptances.
Table 6-12 Command issues and pairing status transition
Command: Pair Creation Pair Splitting
Pairing Status CC: -m cc Simplex -S
(1) SMPL Accepted
(2) to (3)
(2) to (4)
Acceptable
6-42
Data replication operations with CCI
Command Control Interface User and Reference Guide
