Hitachi ZW310 User Manual


1-70

NO.
ZW180 ZW220, ZW250 ZW310
Ampere Corresponding Circuit Ampere Corresponding Circuit Ampere Corresponding Circuit
1 20 SEAT HEATER 15 SEAT HEATER* 15 SEAT HEATER
2 10 DC-DC UNIT 10 DC-DC UNIT 10 DC-DC UNIT
3 (10) OPTION 1 (10) OPTION 1 (10) OPTION 1
4 15 WIPER FRONT 15 WIPER FRONT 15 WIPER FRONT
5 5 HEAD LAMP RH 5 HEAD LAMP RH 5 HEAD LAMP RH
6 10 LIGHTER 10 LIGHTER 10 LIGHTER
7 5 ECM POWER 5 ECU POWER
8 10 POWER ON 10 POWER ON 10 POWER ON
9 20 WORKING LAMP REAR 5 PARKING 5 PARKING
10 5 A/C 1 (10) OPTION 2 (10) OPTION 2
11 5 BACK BUZZER 5 BACK LAMP 5 BACK LAMP
12 10 STOP LAMP 10 STOP LAMP 10 STOP LAMP
13 20 WORKING LAMP FRONT 20 WORKING LAMP FRONT 20 WORKING LAMP FRONT
14 10 HORN 10 HORN 10 HORN
15 5 HEAD LAMP LH 5 HEAD LAMP LH 5 HEAD LAMP LH
16 (15) WIPER SIDE 1 (15) WIPER SIDE 1 (15) WIPER SIDE 1
17 (15) WIPER SIDE 2 (15) WIPER SIDE 2 (15) WIPER SIDE 2
18 (15) GLASS HEATER FRONT (15) GLASS HEATER FRONT (15) GLASS HEATER FRONT
19 (20) GLASS HEATER SIDE (15) GLASS HEATER SIDE (15) GLASS HEATER SIDE
20 (15) GLASS HEATER REAR (10) GLASS HEATER REAR (10) GLASS HEATER REAR
* The seat heater is a standard equipment for the air suspension seat. ( ) stands for optional.

NO.
ZW180 ZW220, ZW250 ZW310
Ampere Corresponding Circuit Ampere Corresponding Circuit Ampere Corresponding Circuit
1 (10) WORKING LAMP YELLOW (10) FOG LAMP (10) FOG LAMP
2 5 PARKING 20 WORKING LAMP REAR 20 WORKING LAMP REAR
3 (10) OPTION 2 5 AC 1 5 AC 1
4 20 AC 2 20 AC 2 20 AC 2
5 10 WIPER REAR 10 WIPER REAR 10 WIPER REAR
6 10 EMERGENCY STEERING 10 EMERGENCY STEERING 10 EMERGENCY STEERING
7 20 IGN 20 IGN 20 IGN
8 15 FLASHER 15 FLASHER 15 FLASHER
9 5 LOAD DUMP 5 LOAD DUMP 5 LOAD DUMP
10 5 RADIO 5 RADIO 5 RADIO
11 10 ROTALY BEACON 10 ROTALY BEACON 10 ROTALY BEACON
12 10 HI BEAM 10 HI BEAM 10 HI BEAM
13 (10) OPTION 3 10 CONTEROLLER 15 FUEL HEATER
14 10 CONTROLLER 10 CONTROLLER
15 30 ECM 30 ECU 10 ECU
16 5 POSITION 1 5 POSITION 1 5 POSITION 1
17 5 POSITION 2 5 POSITION 2 5 POSITION 2
18 10 MCF 10 MCF 10 MCF
19 (10) OPT C/U (10) OPT C/U (10) OPT C/U
20 5 MONITOR 5 MONITOR 5 MONITOR
( ) stands for optional.
