1-11
The engine coolant temperature is indicated with a needle.
When the needle stays in the blue range (1) during opera-
tion, the coolant temperature is normal. If the engine coolant
temperature becomes abnormally high, the stop indicator will
flash and the alarm buzzer will sound. Stop machine operation
and run the engine at slow idle to lower the coolant tempera-
ture. After the coolant temperature lowers, stop the engine for
inspection. In case the needle doesn’t swing at all, Error in the
electrical system is suspected. Contact your nearest HITACHI
dealer for machine inspection.
The transmission oil temperature is indicated with a needle.
When the needle stays in the blue range (3) during operation,
the oil temperature is normal. If the transmission oil tempera-
ture becomes abnormally high (in the red range (2)), the stop
indicator will flash and the alarm buzzer will sound. Stop ma-
chine operation and run the engine at slow idle to lower the oil
temperature. After the oil temperature lowers, stop the engine
for inspection.
The remaining fuel amount is indicated by the needle. Fuel the
machine before the needle indicates the red range (E).
M4GB-01-028
M4GB-01-029
M4GB-01-030
To Next Page
