Honda 2005 VTX1800C User Manual

11
Instruments & Controls
Instruments & Controls
This section shows the location of all
gauges, indicators, and controls you would
normally use before or while riding your
motorcycle.
The items listed on this page are described
in this section. Instructions for other
components are presented in other sections
of this manual where they will be most
useful.
...........................Component Locations . 12
..............Gauges, Indicators & Displays . 18
......................Multi-function Display . 29
......................................Speedometer . 30
........................................Tachometer . 30
...........................................Odometer . 31
...............................Tripmeter A & B . 31
Odometer/Tripmeter A & B/
........................Digital Clock Display . 31
Changing the Speed and
......................................Mileage Unit . 33
.....................................Digital Clock . 34
.............Odometer/TripmeterDisplay . 37
Controls & Features
..................................Ignition Switch . 38
........................................Start Button . 39
...........................Engine Stop Switch . 39
................Headlight Dimmer Switch . 40
............................Turn Signal Switch . 40
.......................................Horn Button . 41
04/08/11 14:26:26 31MCH630_020

Honda 2005 VTX1800C Specifications

General

Engine Type	1795cc liquid-cooled 52° V-twin
Bore and Stroke	101.0mm x 112.0mm
Compression Ratio	9.0:1
Induction	PGM-FI with automatic choke
Transmission	Five-speed
Final Drive	Shaft
Front Suspension	45mm inverted fork
Front Suspension Travel	5.1 inches
Rear Suspension Travel	3.9 inches
Front Tire	130/70R-18
Rear Tire	180/70R-16
Wheelbase	67.5 inches
Ignition	Digital with three-dimensional mapping
Front Brakes	Dual 296mm discs
Rear Brakes	Single 316mm disc
Fuel Capacity	5.3 gallons
