VTX1800F
rearview
mirror
fuel fill cap
turn signal switch
front brake fluid reservoir
indicators
horn button
start button
engine stop
switch
rearview
mirror
headlight
dimmer switch
clutch
lever
front brake
lever
throttle grip
clutch fluid reservoir
multi-function display
12
Component Locations
Instruments & Controls
04/08/11 14:26:31 31MCH630_021

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honda 2005 VTX1800C and is the answer not in the manual?

Honda 2005 VTX1800C Specifications

General IconGeneral
Engine Type1795cc liquid-cooled 52° V-twin
Bore and Stroke101.0mm x 112.0mm
Compression Ratio9.0:1
InductionPGM-FI with automatic choke
TransmissionFive-speed
Final DriveShaft
Front Suspension45mm inverted fork
Front Suspension Travel5.1 inches
Rear Suspension Travel3.9 inches
Front Tire130/70R-18
Rear Tire180/70R-16
Wheelbase67.5 inches
IgnitionDigital with three-dimensional mapping
Front BrakesDual 296mm discs
Rear BrakesSingle 316mm disc
Fuel Capacity5.3 gallons
