Honda 2005 VTX1800C User Manual

VTX1800F
(1)
(2)
(1) odometer
(2) tripmeter
31
Tripmeter A & B
Odometer
Odometer/Tripmeter A & B/
Digital Clock Display
Gauges, Indicators & Displays
Instruments & Controls
The display has three functions:
odometer, tripmeter and digital clock.
Push the mode switch ( ) to select
‘‘TOTAL’’ (odometer) ( ), ‘‘TRIP A’’
(tripmeter A) ( ), ‘‘TRIP B’’ (tripmeter
B) ( ) and ‘‘CLOCK’’ (digital clock) ( )
mode.
The tripmeter ( ) shows number of miles
or kilometers ridden since you last reset
the meter.
The tripmeter has two sub modes, A and B.
The odometer ( ) shows the total miles or
kilometers ridden.
1
3
1
2
45
2
04/08/11 14:29:03 31MCH630_040

Honda 2005 VTX1800C Specifications

General

Engine Type	1795cc liquid-cooled 52° V-twin
Bore and Stroke	101.0mm x 112.0mm
Compression Ratio	9.0:1
Induction	PGM-FI with automatic choke
Transmission	Five-speed
Final Drive	Shaft
Front Suspension	45mm inverted fork
Front Suspension Travel	5.1 inches
Rear Suspension Travel	3.9 inches
Front Tire	130/70R-18
Rear Tire	180/70R-16
Wheelbase	67.5 inches
Ignition	Digital with three-dimensional mapping
Front Brakes	Dual 296mm discs
Rear Brakes	Single 316mm disc
Fuel Capacity	5.3 gallons
