Honda 2005 VTX1800C User Manual

VTX1800F
(1)
(1) mode switch
33
Changing the Speed and
Mileage Unit
Gauges, Indicators & Displays
Instruments & Controls
The speedometer displays both ‘‘mph’’
and ‘‘km/h.’’
The odometer/tripmeter displays both
‘‘mile’’ and ‘‘km.’’
To select ‘‘mph’’/‘‘mile’’ and
‘‘km/h’’/‘‘km’’, push and hold the mode
switch ( ) for more than 2 seconds with
the display in the odometer mode.
1
04/08/11 14:29:22 31MCH630_042

Honda 2005 VTX1800C Specifications

General

Engine Type	1795cc liquid-cooled 52° V-twin
Bore and Stroke	101.0mm x 112.0mm
Compression Ratio	9.0:1
Induction	PGM-FI with automatic choke
Transmission	Five-speed
Final Drive	Shaft
Front Suspension	45mm inverted fork
Front Suspension Travel	5.1 inches
Rear Suspension Travel	3.9 inches
Front Tire	130/70R-18
Rear Tire	180/70R-16
Wheelbase	67.5 inches
Ignition	Digital with three-dimensional mapping
Front Brakes	Dual 296mm discs
Rear Brakes	Single 316mm disc
Fuel Capacity	5.3 gallons
