Honda 2005 VTX1800C User Manual

(1)
RIGHT HANDLEBAR
(2)
OFF
RUN
(1) start button
(2) engine stop switch
39
Start Button Engine Stop Switch
Controls & Features
Instruments & Controls
Starting Procedure,
When the start button is pushed, the starter
motor will crank the engine; the headlight
will automatically go out, but the taillight
will stay on.
The starter motor will not operate if the
engine stop switch is in the OFF position
when the start button is pushed.
The engine stop switch ( ) is used to stop
the engine in an emergency. To operate,
push the switch to the OFF position. The
switch must be in the RUN position to
start the engine, and it should normally
remain in the RUN position even when the
engine is OFF.
The start button ( ) is used for starting the
engine. Pushing the button in starts the
engine. See page .
1
2
56
04/08/11 14:30:16 31MCH630_048

Honda 2005 VTX1800C Specifications

General

Engine Type	1795cc liquid-cooled 52° V-twin
Bore and Stroke	101.0mm x 112.0mm
Compression Ratio	9.0:1
Induction	PGM-FI with automatic choke
Transmission	Five-speed
Final Drive	Shaft
Front Suspension	45mm inverted fork
Front Suspension Travel	5.1 inches
Rear Suspension Travel	3.9 inches
Front Tire	130/70R-18
Rear Tire	180/70R-16
Wheelbase	67.5 inches
Ignition	Digital with three-dimensional mapping
Front Brakes	Dual 296mm discs
Rear Brakes	Single 316mm disc
Fuel Capacity	5.3 gallons
