Brakes
Checking Brake Fluid
1.
Place your motorcycle in an upright
position on a firm, level surface.
2.
Front
Check that the brake fluid reservoir
is horizontal and that the fluid level is
above the LOWER level mark.
3.
Rear
Remove the seat. 2 P. 61
4.
Rear
Check that the brake fluid reservoir
is horizontal and that the fluid level is
between the LOWER level and UPPER
level marks.
If the brake fluid level in either reservoir is
below the LOWER level mark or the brake
lever and pedal freeplay becomes excessive,
inspect the brake pads for wear.
If the brake pads are not worn, you most
likely have a leak. Have your motorcycle
inspected by your dealer.
20170224170119_32MGC6510_eng_BOOK Page 74 Friday, February 24 2017 17:08:26 JST
Maintenance
71
Front brake fluid reservoir
UPPER level mark
LOWER level mark
Rear brake fluid
reservoir
Front Rear
LOWER level mark
To Next Page
