Drive Chain
Inspecting the Drive Chain
Slack
Check the drive chain slack at several points
along the chain. If the slack is not constant at
all points, some links may be kinked and
binding.
Have the chain inspected by your dealer.
1.
Shift the transmission to Neutral. Stop the
engine.
2.
Place your motorcycle on its centre stand
on a firm, level surface.
3.
Check the slack in the lower half of the
drive chain midway between the
sprockets.
Drive chain slack:
25 - 35 mm (1.0 - 1.4 in)
u Do not ride your motorcycle if the
slack exceeds 50 mm (2.0 in).
4.
Rotate the rear wheel and check that the
chain moves smoothly.
5.
Inspect the sprockets. 2 P. 51
6.
Clean and lubricate the drive chain.
2 P. 52
20170224170119_32MGC6510_eng_BOOK Page 78 Friday, February 24 2017 17:08:26 JST
Maintenance
75
