Adjusting the Rear Suspension
#
Spring Preload
You can adjust the spring preload by the
adjuster to suit the load or the road surface.
Turn the adjuster using the pin spanner and
extension bar provided in the tool kit. 2 P. 57
Position 1 is for a decreased spring preload
(soft), or turn to the position 3 to 5 for a
increased spring preload (hard). The
standard position is 2.
20170224170119_32MGC6510_eng_BOOK Page 90 Friday, February 24 2017 17:08:26 JST
Other Adjustments u Adjusting the Rear Suspension
Maintenance
87
Continued
Adjuster
Extension bar
Pin
spanner
CB1100CA
1 2 3 4 5
