447
Refueling
Fuel Information
The hydrogen fuel receptacle is located on the passenger’s rear side of the vehicle.
■
Fuel requirement
■
Hydrogen supply pressure: 70 MPa (10,153 psig) (at 59°F [15°C])
■
Hydrogen filling amount
*1
: Approximately 11 lbs (5 kg) (at 70 MPa [10,153
psig])
*1: A measured value when refueled at a hydrogen station with 70 MPa (10,153
psig) of supply pressure compliant with the SAE (J2601) fueling protocol.
■
Hydrogen tanks capacity: 37.3 US gal (141.3 L) (at 70 MPa [10,153 psig])
■
Hydrogen filling station
To completely fill the hydrogen tank, you need to use a hydrogen filling station that
has an H70 dispenser, which is capable of supplying pressures of up to 10,153 psig
(70 MPa).
Refueling the vehicle is only possible if the pressure inside the hydrogen tank of the
vehicle does not exceed the supply pressure of the filling station.
If you use an H35 dispenser, you will be able to fill only half of the tank.
Compressed hydrogen gas
If improper hydrogen gas is used, the FC stack will be
damaged. Always refuel at authorized hydrogen
filling stations.
2 Refer to the Navigation System Manual
Hydrogen gas is colorless, odorless, very light and
flammable. Also, its burning flame is difficult to
detect by sight.
When refueling hydrogen gas, keep
sources of fire, such as a lit cigarette, away
from the vehicle. As hydrogen gas is highly
flammable, it may cause a fire or explosion.
Be sure to turn the power system to OFF to
stop the FC stack operation.
21 CLARITY FCV CSS-31TRT6400_02.book 447 ページ ２０２０年９月２５日 金曜日 午後３時１５分
To Next Page
