Honda EZ3000CX User Manual

4. TROUBLE SHOOTING
Alternator view
Fig 5-1 ALTERNATOR RESISTANCE TABLE
Item
EZ3000CX
Standard level
Resistance
(Ω)
Limits
Type
R, REH, RK, RA,
CL
K, M, MK
L, LB
S, SB
LS
Rated Voltage【V】
220
230
120
220
230
Frequency 【Hz】
50
60
Main coil
(Black - White)
1.550
0.300
1.100
±10％
Sub coil
(Yellow - Yellow)
2.900
2.400
1.600
±10％
Rotor coil
46.0
±10％
(Ω)
39
BLUE WIRE
SUB WIRING
(SUB COIL)
EARTH
GREEN/YELLOW
WIRE
BRUSH
AC TERMINAL
BLOCK
YELLOW WIRE(－)
BLUE WIRE(＋)
BLACK
WIRE
MAIN WIRING
(Main COIL)
WHITE
WIRE
AVR
YELLOW WIRE
YELLOW WIRE
BRACKET
BROWN WIRE
