Honda GCV160 User Manual

104
2009.01.10 E
E-22
CONTROL(1)
2
6 16576-891-000 HOLDER, CABLE ••••••••••••••• 1 1 - - - - - -------- -------- A1J,A1U,A2U,A4E,BHH,N2D,N2E2
1 - - - - - - -------- 2439633 A1A,A1C,A1E,A1E7,A1E8,A1G7,A1P,A1W2,A1W7,A2A,A2C
A2E,A2E4,A2E7,A2E8,A2E9,A2G7,A3E,A7E1,N1,N1D,N1E1
N1E2,N1E7,N1J1,N1R,N1U,N1W,N1W1,N1W2,N1W7,N1W8
N1W9,N2,N2E,N2E1,N2E3,N2E7,N2E8,N2E9,N2U,N3U,N3V
N7A1
- 1 - - - - - -------- -------- A1A,A1C,A1E7,A1E8,A1W7,A2A,A2C,A2E7,A2E8,A2E9,A2G7
A7E1,N1E7,N1U,N1W7,N1W8,N1W9,N2E7,N2E8,N2E9,N2U
N3V,N7A1
- - - 1 - - - -------- 1239887 A1E7,A1E8,A1G7,A1W7,A2E7,A2E8,A2E9,A2G7,A2G9,A3E7
A7E1,N1E7,N1W7,N1W8,N1W9,N2E7,N2E8,N2E9,N7A1
7 16580-ZM0-000 BASE COMP., CONTROL ••••••••• 1 - - - - - - -------- 1177559 A1A,A1C,A1E,A1J,A1P,A1U,A2A,A2C,A2E,A2U,A3E,A4E,N1
N2
16580-ZM0-800 •••••••••••••••••••••••••••• 1 - - - - - - -------- 1177559 N1D,N1E1,N1E2,N1U,N2D,N2E,N2E1,N2E2,N2E3,N2U
16580-ZM0-J22 •••••••••••••••••••••••••••• 1 1 - 1 - 1 - -------- -------- BHH,EHHB,NBL1,N1J1,N1W2
16580-ZM0-020 •••••••••••••••••••••••••••• 1 - - - - - - -------- -------- A2E4
1 - - - - - - 1177560 -------- A1A,A1C,A1E,A1J,A1P,A1U,A2A,A2C,A2E,A2U,A3E,A4E,N1
N2
- 1 - - - 1 - -------- -------- A1A,A1AS,A1C,A1E,A1M,A2A,A2C,A3E
- - - 1 - - - -------- 2352103 A1P
16580-ZM0-802 •••••••••••••••••••••••••••• 1 1 - - - - - -------- -------- N1W,N1W1,N3U,N3V
1 - - - - - - 1177560 -------- N1D,N1E1,N1E2,N1U,N2D,N2E,N2E1,N2E2,N2E3,N2U
- 1 - 1 - - - -------- -------- N1D,N1E1,N1E2,N1U,N2U
16580-ZM0-V90 •••••••••••••••••••••••••••• 1 1 - - - - - -------- -------- N1R
- - - 1 - - - -------- 2352103 N1R
16580-ZM0-030 •••••••••••••••••••••••••••• - 1 - - - - - -------- -------- A1AW
- - - 1 - - - 2352104 -------- A1P
16580-ZM0-880 •••••••••••••••••••••••••••• 1 - - - - - - -------- -------- N1W8
16580-ZM1-J01 •••••••••••••••••••••••••••• 1 - - - - - - -------- -------- A1W2
Ref.
No.
Part No. Description
Reqd. QTY
Parts catalogue code
GCV GCV GCV GCV GCV GCV GCV
160 160 160 160 160 160 160
A A0 E LE LA LA0
Serial No.
I 1

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
