Honda GCV160 User Manual

March 14,2010
CODE NO.
13ZM00E8
PARTS CATALOGUE NEWS
Honda Motor Co., Ltd. Service Division
PARTS CATALOGUE - CORRECTED
PARTS
CATALOGUE
NEWS
GCV160
GCV160A
GCV160A0
GCV160E
GCV160LE
GCV160LA
GCV160LA0
Printed in Japan NEWS NO. 022
Reqd.QTY
Block
No.
Ref.
No.
Note Part No. Description
GCV GCV GCV GCV GCV GCV GCV
160 160 160 160 160 160 160
A A0 E LE LA LA0
Serial No. Parts catalogue code
E-22 1 T 16551-ZM0-010 ARM, GOVERNOR ................ 1 1 1 1 - 1 1 ------- ------- A1E7,A1E8,A1G7,A1W7,A2E7,A2E8,A2E9,A2G7
A7E1,N1E7,N1J1,N1R,N1W7,N1W8,N1W9,N2E7
N2E8,N2E9,N3U,N7A1
1 - - - - - - 2299008 ------- A1A,A1C,A1E,A1P,A1W2,A2A,A2C,A2E,A2E4
A3E,N1,N1D,N1E1,N1E2,N1U,N1W,N1W1,N1W2
N2,N2E,N2E1,N2E3,N2U,N3V
- 1 1 1 - 1 1 ------- ------- A1A,A1AS,A1AW,A1C,A1E,A1G9,A1M,A1P,A2A
A2A9,A2C,A2G4,A2G9,A3E,A3E7,A3E9,A3G9
A3T9,A3W7,A3W8,A4G4,A4G7,A4G9,BHH,BHH1
C1E,C1E1,C2E,C2E1,C3E,C3E1,C4E,C4E1
EHHB,E1G7,E2G7,NBL1,N1D,N1E1,N1E2,N1T8
N1T9,N1U,N2U,N3T8,N3T9,N3V,N3W8,N3W9
N7S1,SBT,S1E1,S1G4,S2E,S2E1,S2E2,S2E3
S2G7,S3E9,S3G9,S3T,S4E4,S4E9,S4G4,S4G9
- - - - 1 - -
- - - - - - 1 ------- ------- R3A,S1A,S1M,S3A,S3H
3 T 16561-ZM0-V30 SPRING, GOVERNOR ............. 1 1 - 1 1 1 1 ------- ------- A7E1,A7H1,N7A1,N7S1
NOTE A:PART NO.CHANGE D:NEWLY PROVIDED E:PART NO.DELETION K:REQUIRED NO.CORRECTION L:APPLICATION SERIAL NO.CORRECTION
T:APPLICATION CORRECTION Z:REMARKS CHANGE
1/2

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
