Honda GCV160 User Manual

July 13,2009
CODE NO.
13ZM00E8
PARTS CATALOGUE NEWS
Honda Motor Co., Ltd. Service Division
PARTS CATALOGUE - CORRECTED
PARTS
CATALOGUE
NEWS
GCV160
GCV160A
GCV160A0
GCV160E
GCV160LE
GCV160LA
GCV160LA0
Printed in Japan NEWS NO. 014
Reqd.QTY
Block
No.
Ref.
No.
Note Part No. Description
GCV GCV GCV GCV GCV GCV GCV
160 160 160 160 160 160 160
A A0 E LE LA LA0
Serial No. Parts catalogue code
E-15 3 L 17220-ZM0-010 CASE ASSY., AIR CLEANER ...... - 1 - 1 1 - - ------- ------- A1AW,A7H1,S1G4
- 1 - - - - - 6624356 ------- A1E7,A1M,A2E7,BHH1,C1E,C1E1,C2E,C2E1
C3E,C3E1,C4E,C4E1,N1L,N1R,N1U,N2U,N3U
N3V,S2G7,S3H2
- - 1 - - - - ------- 1079019
- - - 1 1 - - 2441542 ------- A1E7,A1E8,A1G7,A1G9,A1P,A1W7,A2E7,A2E8
A2E9,A2G4,A2G7,A2G9,A3E7,A3E9,A3G9,A3T9
A3W7,A3W8,A4A9,A4G4,A4G7,A4G9,A7E1,N1D
N1E1,N1E2,N1E7,N1J1,N1R,N1T8,N1T9,N1W7
N1W8,N1W9,N2E7,N2E8,N2E9,N3T8,N3T9,N3W8
N3W9,S1E1,S2E,S2E1,S2E2,S2E3,S3E9,S3G9
S4E4,S4E9,S4G4,S4G9
- - - - 1 - - 2441542 ------- A2A9,N7A1
- - - - - 1 - 6624356 ------- A1A,A1AF,A2R,BHH,N1A,N1AF,N5AF,N5MF,N5R
N7A1,N7S1,S1A,S1M,S3A,S3H
- - - - - - 1 ------- 1167575 A1A,A1AF,A2R,BHH,E1A2,N1A,N1AF,N5AF
N5MF,N5R,N7A1,N7S1,R3A,S1A,S1M,S3A,S3H
T 17220-ZM0-020 .............................. - - 1 - - - - 1079020
- - - - - - 1 ------- ------- SBT,S3T
- - - - - - 1 1167576 ------- A1A,A1AF,A2R,BHH,E1A2,N1A,N1AF,N5AF
N5MF,N5R,N7A1,N7S1,R3A,S1A,S1M,S3A,S3H
NOTE A:PART NO.CHANGE D:NEWLY PROVIDED E:PART NO.DELETION K:REQUIRED NO.CORRECTION L:APPLICATION SERIAL NO.CORRECTION
T:APPLICATION CORRECTION Z:REMARKS CHANGE
1/2

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
