PARTS CATALOGUE NEWS
BOOKNo.:13ZM00E8
NOTE A:PART NO.CHANGE D:NEWLY PROVIDED E:PART NO.DELETION K:REQUIRED NO.CORRECTION L:APPLICATION SERIAL NO.CORRECTION
T:APPLICATION CORRECTION Z:REMARKS CHANGE
3/3
Reqd.QTY
Block
No.
Ref.
No.
Part No. Description
GCV GCV GCV GCV GCV GCV GCV
160 160 160 160 160 160 160
A A0 E LE LA LA0
Base Part No. Parts catalogue code
E-3 1 12000-Z1L-405 BARREL ASSY., CYLINDER ....... - - - 1 - - -
9 BARREL ASSY., CYLINDER ....... - - - O - - - 12000-ZL8-425
11 VALVE, IN. (ROCKNEL) ......... - - - O - - - 14711-Z0J-000
14711-ZL8-000 VALVE, IN. (TECHNOSTAR) ...... - - - 1 - - -
E-6 1 11300-Z0M-405 PAN ASSY., OIL ............... - - - 1 - - - 11300-ZM0-405
26 91231-891-003 OIL SEAL, 6X11X4(ARAI) ....... - - - 1 - - -
E-11 1 STARTER ASSY., RECOIL
*R280*..............POWER RED - - - O - - -
28400-ZM0-023ZC
E-12 6 COVER COMP., FAN
*R280*..............POWER RED - - - O - - -
19610-Z1L-000ZB
E-14 7 16100-Z0L-013 CARBURETOR ASSY. (BB62W B)... - - - 1 - - - 16100-Z0L-003
E-15 3 17220-ZM0-030 CASE ASSY., AIR CLEANER ...... - - - 1 - - - 17220-ZM0-010
6 17231-Z0L-050 COVER, AIR CLEANER ........... - - - 1 - - - 17231-Z0L-030
E-16 2 18321-ZL8-010 PROTECTOR, MUFFLER ........... - - - 1 - - - 18321-ZL8-000
E-19 13 90201-Z0T-800 NUT, SPECIAL, 14MM ........... - - - 1 - - - 90201-878-003
E-22 7 16580-Z0M-880 BASE COMP., CONTROL .......... - - - 1 - - - 16580-ZM0-882
E-28 32 87524-Z8B-000 MARK, FUEL COCK CAUTION ...... - - - 1 - - -
34 87519-Z0J-000 MARK, OPERATOR CAUTION ....... - - - 1 - - -

Honda GCV160 Specifications

General

Compression Ratio	8.5:1
PTO Shaft Rotation	Counterclockwise (from PTO shaft side)
Cooling System	Forced air
Ignition System	Transistorized magneto
Starting System	Recoil Starter
Engine Type	Air-cooled 4-stroke
Displacement	160 cm3 (9.8 cu in)
Bore x Stroke	68 mm x 45 mm
Net Power Output	3.3 kW (4.4 HP) @ 3, 600 rpm
Oil Capacity	0.55 L (0.58 US qt)
Dimensions	335 mm
